JYF-622-FT Tuya/TTlock Smart Door Lock
Time：2025-06-24 Class：Tuya/TTlock Smart Door Lock Browse：
| Bluetooth Standard |
Bluetooth 5.0 BLE |
| Network Connection |
WIFI (802.11ac) 2.4G |
| Supported Mobile Systems |
Android 4.3/iOS 7.0 and above |
| Power Supply Mode |
7.4V Dual Lithium Battery (Full 8.4V) |
| Low - Power Alarm Voltage |
7.1V |
| Voltage Range |
5 - 9V |
| Standby Current |
596 microamps (including cat's eye, radar, face) |
| Working Current |
≤ 3A (average value) |
| Button Type |
Capacitive Touch Button |
| Password Quantity |
Custom and Permanent Passwords: 250; Other Dynamic Passwords: Unlimited |
| Supported Card Types |
MIFARE MI Card |
| Color Box Size |
488*188*110 |
| Outer Box Size |
570*507*450 |
| Gross Weight of Whole Carton |
26Kg |
| IC Card Quantity |
1000 pcs |
| Unlocking Methods |
APP, Password, Fingerprint, IC Card, Remote Control, Face, Palm Vein |
| Fingerprint Sensor Type |
Semiconductor Fingerprint Sensor |
| Fingerprint Capacity |
50 pieces (adjusted according to the actual model used) |
| False Acceptance Rate (FAR) |
< 0.001% |
| False Rejection Rate (FRR) |
< 1.0% |
| Infrared Resolution |
1600*1200@30fps |
| Color Resolution |
1600*1200@30fps |
| Camera Parameters - Infrared FOV |
H82°, V66°, D85° |
| Camera Parameters - Color FOV |
H96°, V77°, D120° |
| Camera |
2MP |
| Face Storage Capacity |
100 people |
| Palm Storage Capacity |
100 palms |
| Quantity per Carton |
10 PCS |
| Single Weight |
2.5Kg |
