JYC-F11 Hotel Lock System

Time：2026-01-14      Class：Hotel Lock System     Browse：

Panel material	Allumium Alloy
Card specification	Mifare 1 card
Door opening method	Unlock by swiping the card or using a mechanical key - two ways to open the door
Door locking method	Auto-lock when the door is closed
Operating temperature	-20℃~+ 60℃
Relative humidity	20RH—95RH
Operating voltage	DC6V
Alarm voltage	4.1V
Startup time	0.5S
Static current	20uA
Dynamic current	180mA
Power supply used	4 AA 1.5V alkaline batteries
Battery life	10 to 12 months
Lock body size	Standard five-tongue lock body
Frequency	13.56Khz
Lock opening record	can record the last 224 entry records (records can be customized up to 992 in total)
MCU	TI, a USA company
Net weight	2.3KG
box dimensions	305*185*12CM
