JYL-L12EM Locker Lock

Brand Name	Joneytech
Model Number	JYL-L12EM
Unlock way	Card
Door type	Wood door ,Stainless Steel door ,Aluminum door ,Brass door
Battery	4pcs 2A 1.5V batteries
Emergency port	Yes
Certification	CE FCC ROHS
Material	Zinc alloy
Size	44*44*31mm
Working temperature	-30 to 80 degree
Working humidity	95%
Color	Red Bronze
Static power consumption	<5uA
Card type	ID card
ID Card capacity	16pcs
Battery life span	over 115 month
External power interface	Yes
Dynamic power consumption	About 200mA
The battery llif	Open door for 2000 times
Warranty	2 years

　　1) Single card unlocking or double card unlocking both available. (guest card + service card)

　　2) With rebound function – it can be opened smoothly without installing the door handle.

　　3) Low voltage alarm function – if the voltage lower than 4.8V.

　　4) Card in plastic wristband or watchband – waterproof, moisture proof, anti-corrosion.

　　5) Anti-pry alarm function – when unlocking abnormally, the lock will alarm.

　　6) External power supply for emergency unlocking.

　　7) TM card unlocking with more than 100,000 times life span.

　　8) Four level management available – master card, manage card, service card, guest card.

　　Master Card: Only master card in the same system, issue or cancel service card and guest card.

　　Manager Card: Open all locks in the system. (For single card unlocking)

　　Service Card: Open locks in certain area.

　　Guest Card: Open one certain room.
